Micro Precision End Mill/Ball Nose
Changzhou Guangxin Tools Co., Ltd.- Coating：Coating
- Tooth Form：Spiral Tooth
- Tooth Space：Helix Angle
- Structure：Integral
- Material：Carbon Steel
- Type：Slot,Side,Profile Milling
Base Info
- Model NO.：GX1002
- Helix Angle：Customize Angle
- Processed Matertial：Customize
- Quality：High Precision
- Transport Package：Plastic Box+Carton
- Specification：carbide
- Origin：Jiangsu
- HS Code：82077090
- Production Capacity：Hundreds,Day
Description
Basic Info.
Model NO. GX1002 Helix Angle Customize Angle Processed Matertial Customize Quality High Precision Transport Package Plastic Box+Carton Specification carbide Origin Jiangsu HS Code 82077090 Production Capacity Hundreds/DayProduct Description
GX TOOLS-High Precision ToolsAny Non-standard Tools are Available!!!
| Serial No. GX1002... | 010 | 020 | 030 | 035 | 040 | 045 | 050 | 060 | 070 | 080 | 090 |
| R Diameter d | 0.10 | 0.20 | 0.30 | 0.35 | 0.40 | 0.45 | 0.50 | 0.60 | 0.70 | 0.80 | 0.90 |
| Flute Length l1 | 0.40 | 0.80 | 1.20 | 1.40 | 1.60 | 1.80 | 2.00 | 2.50 | 3.00 | 3.50 | 4.00 |
| Shank Dia D | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 | 4 |
| Total Length L | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 | 50 |
Advanced Producing Equipment and Inspection Equipment.
Widely use in aerospace,rail transportation,medical equipment and electronic production,automobile industry .
