• Model NO.：metric and inch
• Material：High Speed Steel
• Type：Cylindrical Reamer
• Size：1,8 to 1-1,2 Inch
• Style：Universal Tool
• Structure：Integral
• Cutting Process：Boring Tool
• Work Type：Cut off
• Standards：64 HRC
• Transport Package：on request
• Specification：M2 steel
• Trademark：stc
• Origin：Jiangsu
• HS Code：82075090
• Production Capacity：5000pcs,month

Basic Info.

Model NO. metric and inch Material High Speed Steel Type Cylindrical Reamer Size 1/8 to 1-1/2 Inch Style Universal Tool Structure Integral Cutting Process Boring Tool Work Type Cut off Standards 64 HRC Transport Package on request Specification M2 steel Trademark stc Origin Jiangsu HS Code 82075090 Production Capacity 5000pcs/month

Product Description

Reamers are precise cutting tools used to enlarge existing holes smoothly and accurately by removing a small amount of metal. Reamer geometry varies widely, which is four or more flutes, spiral or straight, left or right hand cut.

Applications: Reamers are used to rough or finish ream predrilled, punched, or die-cast cavities for improved size, roundness, straightness, and surface finish. Though straight flute reamers are still popular, there are many advantages to spiral flute construction. Particularly in smaller sizes, spiral flute reamers can be manufactured more accurately and result in a considerable cost savings.



Fractional Size (in.)	Decimal Equiv. (in.)	Length Overall(in.)	Length of Flute (in.)
1/8	.1250	3	1-1/2
9/64	.1406	3-1/4	1-5/8
5/32	.1562	3-1/4	1-5/8
11/64	.1719	3-1/2	1-3/4
3/16	.1875	3-1/2	1-3/4
13/64	.2031	3-3/4	1-7/8
7/32	.2188	3-3/4	1-7/8
15/64	.2344	4	2
1/4	.2500	4	2
17/64	.2656	4-1/4	2-1/8
9/32	.2812	4-1/4	2-1/8
19/64	.2969	4-1/2	2-1/4
5/16	.3125	4-1/2	2-1/4
21/64	.3281	4-3/4	2-3/8
11/32	.3438	4-3/4	2-3/8
23/64	.3594	5	2-1/2
3/8	.3750	5	2-1/2
25/64	.3906	5-1/4	2-5/8
13/32	.4062	5-1/4	2-5/8
27/64	.4219	5-1/2	2-3/4
7/16	.4375	5-1/2	2-3/4
29/64	.4531	5-3/4	2-7/8
15/32	.4688	5-3/4	2-7/8
31/64	.4844	6	3
1/2	.5000	6	3
17/32	.5312	6-1/4	3-1/8
9/16	.5625	6-1/2	3-1/4
19/32	.5938	6-3/4	3-3/8
5/8	.6250	7	3-1/2
21/32	.6562	7-3/8	3-11/16
11/16	.6875	7-3/4	3-7/8
23/32	.7188	8-1/8	4-1/16
3/4	.7500	8-3/8	4-3/16
25/32	.7812	8-3/4	4-3/8
13/16	.8125	9-1/8	4-9/16
27/32	.8438	9-3/8	4-11/16
7/8	.8750	9-3/4	4-7/8
29/32	.9062	10	5
15/16	.9375	10-1/4	5-1/8
31/32	.9688	10-5/8	5-5/16
1	1.0000	10-7/8	5-7/16
1-1/16	1.0625	11-1/4	5-5/8
1-1/8	1.1250	11-5/8	5-13/16
1-3/16	1.1875	12	6
1-1/4	1.2500	12-1/4	6-1/8
1-5/16	1.3125	12-1/2	6-1/4
1-3/8	1.3750	12-5/8	6-5/16
1-7/16	1.4375	12-7/8	6-7/16
1-1/2	1.5000	13	6-1/2
