• Model NO.：KY08-4
• Type：Four-Jaw Chuck
• Transport Package：Plywood Case
• Specification：steel
• Trademark：prasteel
• Origin：Nanjing
• HS Code：8466939000
• Production Capacity：3000set,Year

1.The wedge-shaped solid chuck is in line with
  Japanese and Taiwanese standards.
2.All sliding surfaces adopt hardened treatment and
  precision grinding.
3.High rigidity structure and high clamping accuracy Utility model patent number: ZL 2011 2 0346065.3


Four-jaw solid hydraumatic chuck

This is a state-patent product with independent intellectual property.
Connecting way of this chuck and spindle is in accordance with relative national standards. Without need of changing machine tool structure, the user only needs to install flange with corresponding size of the chuck.
With chuck body itself as cylinder and internally-installed piston, the chuck carries out clamping and loosing action by controlling devices in spindle end.
This chuck is solid chuck with the advantage of strong clamping.
The chuck is applicable for processing parts of valves, pumps etc.
