1200mm Nc Rotary Table
Songen Machinery Co., Ltd.- Certification：ISO9001:2000, CE, ISO 9001:2008, GS
- Application：Boring Machine
- Material：Metal
- Type：CNC Controlled
- Table Diameter：1200mm
- Height：390mm
Base Info
- Model NO.：NCRT1200
- Worm Gear Ratio：1:120
- Dividing Accuracy：15"
- Logo Printing：with Logo Printing
- Size：Middle
- Customized：Customized
- Transport Package：Plywood Case
- Specification：Table diameter 1200mm
- Trademark：Songen
- Origin：China
- HS Code：84663000
- Production Capacity：1000 Sets,Year
Description
ParameterNCRT1200 1 Turntable diameter or length X width, mm 1200 2 Total thickness, mm 390 3 Center bore diameter, mm 135H6X15 4 T-slot size, mm 8-22H12 5 Worm gear ratio 1:120 6 Total reduction ratio 1:360 7 Max. speed, RPM 3.7 8 Table graduation angle per impulse, Deg 0.001 9 Servo motor (optional) output power, KW ≥3.8 10 Standard electromotor, FANUC α22 11 Horizontal loading capacity, Kgf 4000 12 Clamping torque, N.M Oil 1.5MPa 6150 Air 0.5MPa 2050 13 Max. torque capacity of worm gear, N.M 4000 14 Max. rotary interia of workpiece, kg.cm.s2 6428 15 Dividing accuracy, Sec 15 16 Repeatability accuracy, Sec 4 17 Radial runout accuracy, mm 0.005 18 Top face runout accuracy, mm 0.015 19 Torque of servo motor, N.m 22 20 Net weight, Kgs 1598
