Senyo Solid Carbide Mzr High Performance Turning Tool
Changzhou Senyo Cutting Tools Co., Ltd.- Application：Woodworking Machine, Grinding Machine, Milling Machine
- Structure：Overall Tool
Base Info
- Model NO.：MZR4*R0.5*L15
- Material：Cemented Carbide
- Type：Boring Turning Tool
- HRC：45-65 HRC
- Precision：High Precision
- Transport Package：Plastic Box
- Trademark：Senyo
- Origin：Changzhou
- HS Code：8207709000
- Production Capacity：20000
- Package size per unit product：17.50cm * 9.50cm * 11.50cm
- Gross weight per unit product：0.200kg
Description
MZR Series Specification D L L1 R W H F Min Working Diameter Applicable Handle 4 R0.5 L15 4 51 15 0.5 1 1.2 1.95 5 NC1604-100 4 R0.75 L15 4 51 15 0.75 1.5 1.5 1.95 5 NC1604-100 5 R0.5 L22 5 51 22 0.5 1 1.2 2.45 6 NC1605-100 5 R0.75 L22 5 51 22 0.75 1.5 1.5 2.45 6 NC1605-100 5 R1.0 L22 5 51 22 1 2 2.5 2.45 6 NC1605-100 6 R0.5 L22 6 51 22 0.5 1 1.2 2.95 8 NC1606-100 6 R0.75 L22 6 51 22 0.75 1.5 1.5 2.95 8 NC1606-100 6 R1.0 L22 6 51 22 1 2 2.5 2.95 8 NC1606-100
