• Model NO.：end mills
• End Mill Flute Diameter：D0.5-D30mm
• Precision：High Precision
• Controlling Mode：CNC Tooling System
• Usage：General High Speed Cutting
• Package：1 PC in a Plastic Tube, 10 PCS Per Group
• Work Piece：HRC 45, 50, 60, 65
• Transport Package：Air
• Specification：SGS
• Trademark：Hiboo
• Origin：Changzhou Jiangsu, China
• HS Code：8207709000
• Production Capacity：50000pieces,Mouth

Basic Info.

Model NO. end mills End Mill Flute Diameter D0.5-D30mm Precision High Precision Controlling Mode CNC Tooling System Usage General High Speed Cutting Package 1 PC in a Plastic Tube, 10 PCS Per Group Work Piece HRC 45, 50, 60, 65 Transport Package Air Specification SGS Trademark Hiboo Origin Changzhou Jiangsu, China HS Code 8207709000 Production Capacity 50000pieces/Mouth

Product Description

Details
Type: Flat/Ball Nose/Corner Radius/Roughing/Long Neck
Certification: SGS
Flute: 2,3,4,5,6flutes
Processing: Steel,Aluminum,etc
Trademark:ANTIAN
Specification: 3-20x200mm
HS Code: 8207709000
Logo Printing: with Logo Printing
Customized: Standard and Costomized
Material: Tungsten Carbide
Work Piece: 45, 55, 60, 65, 68,etc.
Length: 50,60-150,200,Costomized
Coating: Altin/Tiain/Ticn/Tin/Tialn/Uncoated
Transport Package: Plastic Box/Standard Carton




Description

Products Name	Carbide endmill cutter
Work piece	HRC45 , HRC55 , HRC60 , HRC65 , HRC68
Coating Type	ALTIN  , TiAIN ,Ticn ,Tin ,Tialn ,Uncoated
Size	Standard sizes or customized sizes
Logo	According your requests
TRS	>3600 N/mm2
Hardness	HRA 91.8-92.5
Helix angle	30°-45 °
Diameter of cutting edge	0.2-0.9 mm; 1-20 mm
Length	50,60-100 mm
Flutes No.	2/3/4/5/6/7/8/9,etc
Cutting Form	Flat, Square, Ball nose, Corner Radius, Long neck,Roughing,etc
MOQ	1pc
Samples time	7 dyas
OEM	Acceptable
Stock	Rich
Certification Available	ISO 90001
Production Capacity	500000 pcs per month
Payment terms	T/T,  PAYPAL, WESTERN UNION,MONEY GRAM
Packing Details	Plastic pipe in carton box with full of bubble paper and foam with 33cm*23cm*19cm

Application
Used for cutting Carbon steel, Tool steel, Mould steel, Stainless steel, Titanium alloy, Copper, Cast Iron and Aluminium, etc


 Coating

Coating	Color	Coating Temperature	Thickness (um)	HV	Application Temperature	Friction coefficient
TiAlN	Purple-Gray	<600°C	3-5	3300	800 °C	0.3
AlTiN	Black	<600 °C	3-5	3500	900 °C	0.3
TiSiN	Copper	<600 °C	3-5	3500	1500 °C	0.4
NaNo	Blue	<600 °C	3-5	3800	1200 °C	0.4
CrN	Silver Gray	<480 °C	2-2.5	2500	700 °C	0.3

 Packing
Brand Laser printed on cutter shank,  1 pcs in a plastic tube, 10 pcs a group
