Super Angle Lock Precision Swivel Base Milling Machine Vise
Laizhou Hongzun Machinery Co., Ltd.- Certification：ISO9001:2008, CE
- Application：Milling Machine, Drilling Machine
- Jaw Width：160 mm
- Shape：Without Anvil
- Material：Stainless Steel
- Type：Rotary
Base Info
- Model NO.：QM16160L
- Product Name：Super Angle Lock Swivel Base Milling Machine Vise
- Model No.：Qm16160L
- Width of Jaw：160 mm
- Height of Jaw：45 mm
- Total Height：157 mm
- Max Opening：200 mm
- G.W.：37kgs
- N.W.：36kgs
- Qty/CTN：1 PCS
- CTN Size：48X32X18 Cm
- Transport Package：Plywood Case & Cartons
- Specification：CE,ROHS,UL,CSA
- Trademark：HONGZUN
- Origin：Yantai Shandong
- HS Code：8465950000
- Production Capacity：200PCS,Month
Description
Fixed base:
| Model NO. | Width Of Jaw(mm) | Height Of Jaw(mm) | Max.Opening(mm | G.w./N.w.(kgs) | Q'ty/Ctn(pcs) | Packing Size(cm) |
| QM16100F | 100 | 32 | 100 | 14/13 | 1 | 36X25X13 |
| QM16125F | 125 | 40 | 125 | 18/17 | 1 | 41x27x13 |
| QM16160F | 160 | 45 | 160 | 26/25 | 1 | 45x32x14 |
| QM16160LF | 160 | 45 | 200 | 28/27 | 1 | 48x32x14 |
| QM16200F | 200 | 50 | 220 | 41/40 | 1 | 56X36X26 |
| QM16250F | 265 | 70 | 290 | 96/88 | 1 | 75X40X21 |
Product feature:
• It is one of main attachments for milling, drilling machine, it is particularly suitable for the finishing of precision parts.• The accurancy of vise (parallelism and squareness ) is 0.025mm/100mm.
• The special segment in the movable jaw forces the vertical pressure downward when the horizontal pressure works, so that this jaw does not lift the workpiece.
• These units can be ordered separately or with swivel base.
• Four positions allow extra capacity to change opening of jaw.
