Inch HSS Cutting Keyway Broaches Set with Shims

Qingdao Preco Imp. & Exp. Co., Ltd.
  • Coating：Uncoated
  • Blade Number：Multi-Blade

Base Info

  • Material：High-Speed Steel
  • Type：Cutter
  • Size：Inch
  • Hardness：HRC61~63
  • Delivery：15~30 Days
  • Standards：M
  • Style：Forming Tool
  • Structure：Integral
  • Cutting Process：Milling Cutter
  • Work Type：Internal Work
  • Transport Package：Plastic Rube or Wooden Boxes
  • Specification：ISO 9001
  • Trademark：Neutral or OEM
  • Origin：China
  • Production Capacity：Enough for Export
  • Package size per unit product：20.00cm * 17.00cm * 17.00cm
  • Gross weight per unit product：8.000kg

Description

Item No.Specification  Keyway Broach HSS(INCH)395-10041/16-A 1/8x5" 0 shims min.13/64, max.1-1/8,Tol..0625-.0635395-10063/32-A 1/8x5" 0 shims min.13/64, max.1-1/8,Tol..0938-.0948395-10081/8-A 1/8x5" 1shims min.13/64, max.1-1/8,Tol..1252-.1262395-11063/32-B 3/16x6-3/4" 0 shims min.19/64,max.1-11/16, Tol..0937-.0947395-11081/8-B 3/16x6-3/4" 1shims min.19/64,max.1-11/16, Tol..1252-.1262395-11123/16-B 3/16x6-3/4" 1shims min.19/64,max.1-11/16, Tol..1877-1887395-12123/16-C 3/8x11-3/4" 1shims min.25/64, max.2-1/2,Tol. .1877-.1887395-12161/4-C 3/8x11-3/4" 1shims min.25/64, max.2-1/2,Tol. .2502-.2512395-12205/16-C 3/8x11-3/4" 2shims min.25/64, max.2-1/2,Tol. .3127-.3137395-12243/8-C 3/8x11-3/4" 2 shims min.25/64, max.2-1/2,Tol. .3755-3765395-13245/16-D 9/16x13-7/8" 2 shims min.1, max.6, Tol..3127-.3137395-13283/8-D 9/16x13-7/8" 2 shims min.1, max.6, Tol..3755-.3765395-13327/16-D 9/16x13-7/8" 3 shims min.1, max.6, Tol..4380-.4390395-13361/2-D 9/16x13-7/8" 3 shims min.1, max.6, Tol..5006-.5016395-14405/8-E 3/4x15-1/2" 4 shims min.1, max.6 Tol..6260-.6270395-14483/4-E 3/4x15-1/2" 5 shims min.1, max.6 Tol..7515-7525395-15567/8-F 1x20-14" 6 shims min.1, max.6,Tol..8765-.8775395-15641-F 1x20-14" 7 shims min.1, max.6,Tol.1.0015-1.0025395-15701-1/8 1-1/8x20-1/4" 8 shims min.1, max6,Tol.1.1265-1.1275395-15721-1/4 1-1/4x20-1/4" 9 shims min.1-1/2,max.8,Tol.1.2520-1.2530395-15741-3/8 1-3/8x20-1/4" 10 shims min.1-1/2,max.8,Tol.1.3770-1.3780395-15761-1/2 1-1/2x20-1/4" 11 shims min.1-1/2,max.8,Tol.1.5020-1.5030
To know more abut our Cutting Broaches, please directly contact us to get prompt assistance.
