• Model NO.：end mill
• Diameter：1-20mm
• Certification：Ce, ISO 9001
• Work Piece：HRC 45, 50, 60, 65
• Suitable for：Carbon Steel
• Usage：General High Speed Cutting
• Package：1 PC in a Plastic Tube, 10 PCS Per Group
• End Mill Flute Diameter：D0.5-D30mm
• Precision：High Precision
• Controlling Mode：CNC Tooling System
• Application：CNC Process
• Transport Package：Plastic Box
• Specification：SGS
• Trademark：Hiboo,customized
• Origin：Changzhou Jiangsu China
• HS Code：8207709000
• Production Capacity：50000PCS,Mouth

Basic Info.

Model NO. end mill Diameter 1-20mm Certification Ce, ISO 9001 Work Piece HRC 45, 50, 60, 65 Suitable for Carbon Steel Usage General High Speed Cutting Package 1 PC in a Plastic Tube, 10 PCS Per Group End Mill Flute Diameter D0.5-D30mm Precision High Precision Controlling Mode CNC Tooling System Application CNC Process Transport Package Plastic Box Specification SGS Trademark Hiboo/customized Origin Changzhou Jiangsu China HS Code 8207709000 Production Capacity 50000PCS/Mouth

Product Description

Products Description

3flutes aluminium processing end mills manufacturers
HRC: 50-55
Helix degree 45/55

HRC45	HRC55	HRC60	HRC65
YG10X	YG10.2 &WF25(Taiwan)	K44 & K40	Sandvik H10F
Grain Size:0.7um Co:10 % Flexural strength: 3800N/mm2	Grain Size:0.6um Co:10 % Flexural strength: 4000N/mm2	Grain Size:0.5um Co:12 % Flexural strength: 4300N/mm2	Grain Size:0.4um Co:12.5 % Flexural strength: 4300N/mm2

1mm-25mm
1/2/3 Flute
 High polishing






Super Coating

	AlTiN	TiAIN	TiSiN	Nano
Hardness(HV)	3200	2800	3600	42(GPA)
Thickness(UM)	2.5-3	2.5-3	3	3
Oxidation Temp(°)	900	800	1000	1200
Friction Coeffient	0.3	0.3	0.45	0.4
Color	Black	Violet	Copper	Blue

Made by world latest 5-AXIS CNC tools grinder, promise the quality and precision of cutter.

Each end mill is inspected by Zoller measuring and inspected machine.

Package and shipping details
Laser brand on the cutter's shank for free , 1 pc in a plastic tube , 10pcs a group,
outside paper carton,carton size:37x26x17cm ,about 1000pcs 4mm cutters in a carton


Hiboo Shipping and delivery
For samples , we dispatch your tools in 7 workdays .
For formal orders,We delivery tools to you in 7-30 workdays , it will depond on your order quantity .

Payment Term
T/T ,Western Union , MoneyGram,L/C and others
