• Model NO.：250x2.0x32mm Sierra
• Type：HSS Saw
• Hardness：HRC62-65
• Usage：Metal Tube Cutting
• Tooth Grinding：CNC Tooth Grinding Machine
• Delivery Time：6 Weeks After Order.
• Transport Package：Carton+Pallet
• Specification：250x2.0x32mm
• Trademark：FUWEISI, BOSS CUT.
• Origin：China, Germany, Japan, USA Material
• HS Code：82023990
• Production Capacity：30000PCS Per Month.

Basic Info.

Model NO. 250x2.0x32mm Sierra Type HSS Saw Hardness HRC62-65 Usage Metal Tube Cutting Tooth Grinding CNC Tooth Grinding Machine Delivery Time 6 Weeks After Order. Transport Package Carton+Pallet Specification 250x2.0x32mm Trademark FUWEISI, BOSS CUT. Origin China, Germany, Japan, USA Material HS Code 82023990 Production Capacity 30000PCS Per Month.

Product Description

FUWEISI Hiqh quality HSS 1.3343 Circular Saw Blade For Tube & Profile Cutting.

Type:
        PVD coated RED PLUS
Tooth form:
       A / AW / B / BW / HZ
Diameter:
       200mm; 225mm, 275mm, 300mm,
       315mm, 350mm, 370mm, 400mm, 425mm, 450mm,500mm
Thickness:
       1.2mm; 1.6mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm. 4.0mm.
Bore diameter:
        32mm, 38mm, 40mm, 50mm or customer bore size.

Technical data of coating:
             Colour: RED plus
             Process: PVD
             Hardness: 2500HV
             Friction: 0.4
             Thickness: 1-4mm.
             Max cutting temperature: 600 degree.

Operation:
        Structural steel
        Alloyed steels
        Steel pipes and profiles
        Pipes and profiles out non ferrous metals

Technical recommendation:
           Raising of the coating hardness by reducing the friction
           Universal coating for better sawblade life
           50-100%higher speed and feed rates
           Prevention of side pick-UPS

Production is based on DIN standards 1836, 1837, 1838 and 1840, extended by the refined "FUWEISI" manufacturing standards. The delivery program consists of a range of standard sawblades which can be delivered from stock and a range of special sawblades to be produced to customer specifications.

The HSS TIN sawblades are supplied as standard in high speed steel grade M2 = DIN 1.3343. It suits for the cutting of the materilas like stainless steel, iron pipe, steel pipe, etc.

All the products haven been enjoying an excellent reputation in the world market for it's competitive price and excellent quality.
