• Model NO.：27x0.9x6,10TPI
• Type：Band Saw
• Hardness：HRC67-69
• Material：Tungsten Carbide
• Tpi：6,10t
• Appllication：Die Steel or Alloy Steel Cutting.
• Delivey Time：4-6 Weeks After Order.
• Transport Package：Carton, Wood, Pallet.
• Specification：27X0.9X6,10TPI M42
• Trademark：FUWEISI, BOSS CUT
• Origin：China
• HS Code：8202911000
• Production Capacity：3000000meter ,Month

Specifications
Teeth forms
10/14
8/12
6/10
5/8
4/6
3/4
2/3
1.4/2
1/1.5
1.7/2.5
0.75/1
0.75/1.2527mmx0.9    OK  OK  OK OKOK OK OK     34mmx1.1    OK  OK  OK OKOK OK OK     41mmx1.3    OK  OK  OK OKOK OK OK  OK   OK    OK  54mmx1.6
    OK OK  OK   OK    OK    OK     OK67mmx1.6      OK OK  OK   OK    OK    OK     OK80mmx1.6      OK OK  OK   OK    OK    OK     OKFront AngleThe range of the cutting materialSteel typesNote0°1.the profile angle is bigger and the strength is higher, so it's suitable for cutting different kinds of the material
 It's better to choose the bigger front tooth agnle when the stiffness for the procee system  is poor or the power for the saw machines is shortage0°~5°1.suitable for cutting brittle materials;Such as: gray cast iron,
High speed steel and chilled cast iron, tool steel, alloy steel, spring steel, high quality carbon structural steel, bearing steel, steel, martensite stainless steel and heat resistant steel
(HT200,65Mn,W18Cr4V,T12,50Cr,60Si2MnA,1Cr12,1Cr13,GCr15)2.suitable for cutting hard material;3.Suitable for interrupted cutting or the forging ,casting with crustaceous;4.applicable to small section,thin walled pipe6°~10°1.applicable to the workpiece material strength,low hardness, and good plasticitySuch as: ordinary carbon structural steel, high quality carbon structural steel, alloy steel, carbon tool steel and austenitic stainless steel, nodular cast iron, nonferrous metals
(Q235-A,20,30,45,T10,40Cr,20CrMo,1Cr18Ni9Ti,Cu
And so on)
 2.suitable for cutting solid material,thick walled pipes

Material cross -section	TPI
<30mm	10/14
20-50mm	8/12
25-60mm	6/10
35-80mm	5/8
50-100mm	4/6
70-120mm	4/5
80-150mm	3/4
120-350mm	2/3
250-600mm	1.4/2.0
500-1200mm	0.75/1.25
1000-3000mm	0.55/0.75

FUWEISI band saw blades will be produced suitable to the following band sawing machines:


AMADA	ELSELE	KALTENBACH	MULLER
BAUER	EVERISING	KASTO	PEDRAZZOLI
BEHRINGER	FMB	KLAEGER	PEHAKA
BERG & SCHMID	FORTE	MARVEL	RES
BIANCO	FRIGGI	MEBA	RUSCH
BTM	HEM	MEGA	SABI
COSEN	HESKA	MEP	SPM
DAITO	HYD MECH	METALIN	UZAY MAKINA
DANOBAT	INDORE	METORA	WAGNER
DELTA	JAESPA	MISSLER	WAY TRAIN
DOALL	JJ MACHINE TOOLS	MOSSNER	WOO SUNG
