HSS Cylindrical Milling Cutters
Zhenjiang Scharp Machinery Tools Co., Ltd.- Coating：Uncoated
- Tooth Form：Spiral Tooth
- Tooth Space：Sparse Tooth
- Structure：Integral
- Material：High Speed Steel
- Type：Vertical Milling Cutter
Base Info
- Model NO.：metric and inch
- Size：2-1,4 to 4 Inch
- Style：Universal Tool
- Cutting Process：Milling Cutter
- Work Type：Cut off
- Standards：64 HRC
- Transport Package：Plastic Box
- Specification：2-1,4 to 4 inch
- Trademark：stc
- Origin：Jiangsu
- HS Code：82077090
- Production Capacity：1000PCS,Month
Description
SizeHole Diameter Length of Cut
Size Hole Diameter Length of Cut
Size Hole Diameter Length of Cut
2-1/2" 1" 2"
3" 1-1/4" 2"
4" 1-1/2" 2"
2-1/2" 1" 3"
3" 1-1/4" 2-1/2"
4" 1-1/2" 3"
2-1/2" 1" 4"
3" 1-1/4" 3"
4" 1-1/2" 4"
3" 1-1/4" 1-1/2"
3" 1-1/4" 4"
4" 1-1/2" 6"
Metric Size DIN884
Size Hole Diameter Length of Cut
Size Hole Diameter Length of Cut
Size Hole Diameter Length of Cut
50 22 40
63 27 70
100 40 63
50 22 50
63 27 80
100 40 70
50 22 63
80 32 50
100 40 100
50 22 80
80 32 63
100 40 125
63 27 50
80 32 80
63 27 63
80 32 100
