• Model NO.：Customized
• Type：Carbide Saw Blade
• Outside Diameter：35~380mm
• Material：Tungsten Carbide
• Standards：K
• Style：Universal Tool
• Structure：Special Type
• Cutting Process：Turning Tools
• Work Type：Cut Off
• Transport Package：Carton Box
• Specification：ISO
• Trademark：Excelledge
• Origin：Chengdu, China
• HS Code：82090000
• Production Capacity：20, 000 PCS,Month

Basic Info.

Model NO. Customized Type Carbide Saw Blade Outside Diameter 35~380mm Material Tungsten Carbide Standards K Style Universal Tool Structure Special Type Cutting Process Turning Tools Work Type Cut Off Transport Package Carton Box Specification ISO Trademark Excelledge Origin Chengdu, China HS Code 82090000 Production Capacity 20, 000 PCS/Month

Product Description

Tungsten Carbide Disc Cutter is made by fine or super fine grade size material with advanced sintering technology, which is excellent in hardness and wear resistance.
The cutting edges can be machined according to your own specification.

The purposes of Disc Cutters is used for rubbers, corrugated papers, stones, and non-ferrous metals.

Recommend Grades of Tungsten Carbide Disc Cutters are as follows:

Grade	Density	Hardness (HRA)	Bending Strength (/Mpa)	Performance and Application	Equivalent ISO Grade
YG3X	15.0~15.3	92	1320	Fine Grain Size, outstanding in hardness, which is used to high speed finishing of cast iron, non-ferrous alloy, and  alloy hardened steel, and alloy steel.	K01
YG3	15.0~15.3	91	1200	Excellent in hardness, and suitable for finishing of cast iron, non-ferrous alloy, and plastic, rubber, etc.	K01
YG6X	14.6~15.0	91	1400	Fine grain size. Excellent in wear resistance.Be used to process ferrous steel (HB<200), glass, hard rubber, cardboard, marble, ceramic copper alloy etc.	K10
YG6	14.6~15.0	89.5	1450	Be used to process ferrous steel(HB<200),non-ferrous metal, wood, plastic, etc.	K20
YG8	14.5~14.9	89	1500	Rough and semi-finishing of cast iron, nonferrous metal, wood, plastic, etc.	K30
YG11C	14.0~14.4	86.5	2100	Grade for manufacturing nozzle, wear resistance parts, die insert, mining tool, measuring tool like gauge, micrometer etc	K40
YG15	13.9~14.2	87	2100	Grade for manufacturing nozzle, wear resistance parts, die insert, mining tool, measuring tool like gauge, micrometer etc	K40
