• Model NO.：JAB
• Type：Two-Jaw Chuck
• Transport Package：Wooden Package, Water-Proof Film Wrapped
• Specification：380x380x133mm
• Trademark：CHANGYI
• Origin：Wuxi, China
• HS Code：7326901900
• Production Capacity：5000 PCS Per Year

Basic Info.

Model NO. JAB Type Two-Jaw Chuck Transport Package Wooden Package, Water-Proof Film Wrapped Specification 380x380x133mm Trademark CHANGYI Origin Wuxi, China HS Code 7326901900 Production Capacity 5000 PCS Per Year

Product Description

JAB High speed rotary type pneumatic chuck

1. This chuck can be used in either internal or external clamp configurations.
2. Heat-treated steel integrally formed structure, bearing no load, high speed, long life and low temperature rise.
3. Two-way power, forced open collet, never jam. When the air source is interrupted, the collet is self-locking.
4. The direct flange is connected to the main shaft for quick and easy installation. It can be connected to the machine system through a three-point combination valve.
5. Quickly change the collet to facilitate product replacement, the collet does not retract, and the working length can be controlled normally.
6. The body accuracy is within 0.01mm.

Product suitability:

1. NC lathes, lathes, grinding machines, indexing plates, 4/5 axes.
2. Turning of batch work pieces.

Performance parameters

Model/Spec.	Max. Speed (rpm)	Piston stroke (mm)	Clamping stroke (mm)	Max. Torque (N.M)	Working pressure (kg/cm2)	Max. Chuck diameter (mm)	Use collet	Net weight	Max. Working pressure (kg)
JAB-15	4000	4	1.5-2	3N.M	3-8	Φ2-15	YB-15	3.2	3-8kg
JAB-25	4000	4	1.5-2	15N.M	3-8	Φ5-25	YB-25	9.5	3-8kg
JAB-40	4000	4	1.5-2	30N.M	3-8	Φ5-40	16C	13.5	3-8kg
JAB-60	4000	4	1.5-2	35N.M	3-8	Φ5-60	20C	20.35	3-8kg
