• Model NO.：1.5mm to 30mm
• Material：High Speed Steel
• Type：Cylindrical Reamer
• Size：3mm to 30mm
• Standards：K
• Style：Universal Tool
• Structure：Integral
• Cutting Process：Boring Tool
• Work Type：Cut off
• Transport Package：on request
• Specification：1.5mm to 30mm
• Trademark：stc
• Origin：Jiangsu
• HS Code：82075090
• Production Capacity：5000pcs,month

Basic Info.

Model NO. 1.5mm to 30mm Material High Speed Steel Type Cylindrical Reamer Size 3mm to 30mm Standards K Style Universal Tool Structure Integral Cutting Process Boring Tool Work Type Cut off Transport Package on request Specification 1.5mm to 30mm Trademark stc Origin Jiangsu HS Code 82075090 Production Capacity 5000pcs/month

Product Description

DIN 206.METRIC HAND REAMERS with Parallel Shank and Squared End.High Speed Steel.Right Hand Cut.Range of application:Iron and non-ferrous.

Din206 A is straight flute hand reamer;
Din206 B is low helix flute hand reamer;

cutting diameter	flute length	total length
1.5	25	50
2	25	50
2.5	29	58
3	31	62
3.5	35	71
4	38	76
4.5	41	81
5	44	87
5.5	47	93
6	47	93
6.5	47	93
7	54	107
7.5	54	107
8	58	115
8.5	58	115
9	62	124
9.5	62	124
10	66	133
10.5	66	133
11	71	142
11.5	71	142
12	76	152
12.5	76	152
13	76	152
14	81	163
15	81	163
16	87	175
17	87	175
18	93	188
19	93	188
20	100	201
22	107	215
25	115	231
28	124	247
30	124	247
