Cobalt 5 High Speed Steel Ground End Mills
Zhenjiang Scharp Machinery Tools Co., Ltd.- Coating：Coating
- Tooth Form：Spiral Tooth
- Tooth Space：Sparse Tooth
- Structure：Integral
- Material：High Speed Steel
- Type：Vertical Milling Cutter
Base Info
- Model NO.：metric and inch
- Size：2mm to 63mm
- Standards：64HRC
- Style：Universal Tool
- Cutting Process：Milling Cutter
- Work Type：Spot Facing Work
- Transport Package：Palstic Box
- Specification：2mm to 63mm
- Trademark：stc
- Origin：Zhenjiang
- HS Code：82074090
- Production Capacity：10000PCS,Month
Description
STC047-1, REGULAR LENGTH
Size Shank Diameter Flute Length Overall Length
Size Shank Diameter Flute Length Overall Length
Size Shank Diameter Flute Length Overall Length
2 6 7 51
10 10 22 72
28 25 45 121 2.5 6 8 52
12 12 26 83
32 32 53 133 3 6 8 52
14 12 26 83
36 32 53 133 4 6 11 55
16 16 32 92
40 40 63 155 5 6 13 57
18 16 32 92
45 40 63 155 6 6 13 57
20 20 38 104
50 50 75 177 7 10 16 66
22 20 38 104
56 50 75 177 8 10 19 69
25 25 45 121
63 50 90 192
STC047-2, LONG LENGTH
Size Shank Diameter Flute Length Overall Length
Size Shank Diameter Flute Length Overall Length
Size Shank Diameter Flute Length Overall Length
2 6 10 54
10 10 45 95
28 25 90 166 2.5 6 12 56
12 12 53 110
32 32 106 186 3 6 12 56
14 12 53 110
36 32 106 186 4 6 19 63
16 16 63 123
40 40 125 217 5 6 24 68
18 16 63 123
45 40 125 217 6 6 24 68
20 20 75 141
50 50 150 252 7 10 30 80
22 20 75 141
56 50 150 252 8 10 38 88
25 25 90 166
63 50 190 282
