Bt/Jt/Sk/Dat/Nt/St/Cat Tool Holder, Bt40-Sln Milling Arbor
Yantai Formore Machinery Co., Ltd.- Coating：Uncoated
- Tooth Form：Straight Tooth
- Tooth Space：Sparse Tooth
- Structure：Insert Type
- Material：Carbon Steel
- Type：Side Milling Cutter
Base Info
- Model NO.：BT40-SLN
- Application：CNC Machine
- Transport Package：Cases
- Specification：100x100x50mm
- Trademark：Neutral
- Origin：China
- HS Code：84661000
- Production Capacity：10000PCS,Year
Description
Basic Info.
Model NO. BT40-SLN Application CNC Machine Transport Package Cases Specification 100x100x50mm Trademark Neutral Origin China HS Code 84661000 Production Capacity 10000PCS/YearProduct Description
Features:
Spindle conicity standard:JIS MAS 403 BT
Bore tolerance:H5
Applied for remachining with rigidity clamp
Face mill chuck used to be the holder of cutting tools.
When attaching cutting tools with strong side aligned lock between the plane of the part and notch solid screws.
The pull stud is ordered specially.
