American National Standard Woodruff Keyseat Cutters Straight Teeth

Zhenjiang Scharp Machinery Tools Co., Ltd.
  • Coating：Uncoated
  • Tooth Form：Spiral Tooth
  • Tooth Space：Sparse Tooth
  • Structure：Integral
  • Material：High Speed Steel
  • Type：Vertical Milling Cutter

Base Info

  • Model NO.：metric and inch
  • Size：4.5mm to 32.5mm
  • Style：Universal Tool
  • Cutting Process：Milling Cutter
  • Work Type：Cut off
  • Standards：64HRC
  • Transport Package：Plastic Box or Wooden Case
  • Specification：12mm to 32mm
  • Trademark：stc
  • Origin：Zhenjiang Jiangsu
  • HS Code：82077090
  • Production Capacity：5000PCS,Month

Description

Basic Info.

Model NO. metric and inch Size 4.5mm to 32.5mm Style Universal Tool Cutting Process Milling Cutter Work Type Cut off Standards 64HRC Transport Package Plastic Box or Wooden Case Specification 12mm to 32mm Trademark stc Origin Zhenjiang Jiangsu HS Code 82077090 Production Capacity 5000PCS/Month

Product Description

American National Standard Woodruff Keyseat Cutters Straight TeethAmerican National Standard Woodruff Keyseat Cutters Straight TeethAmerican National Standard Woodruff Keyseat Cutters Straight TeethAmerican National Standard Woodruff Keyseat Cutters Straight Teeth


The woodruff Key seat Cutter is a circular Cutter integral with a parallel shank for holding and driving having definite diameter and width with sides slightly concave designed for cutting seating in shafts for woodruff keys

M2, High speed steel.  M35 available on request.

Woodruff keyseat cutters two types straight teeth and staggered teeth.

sets available on request.

1/2" shank straight tooth standard.

DIN 850, GOST 6648 ANSI B 94.11
Dia.
MM
 		Width  of
MM
 		Dia.  of
Shank
 		Overall
Length
 		Woodruff  Key
To  ISO  2294

10.5
10.5
10.5
 		2
2.5
3
 		6.0
6.0
6.0
 		50
50
50
 		2 x 3.7
2.5 x 3.7
3 x 3.7

13.5
13.5
 		3
4
 		10
10
 		56
56
 		3 x 5
4 x 5

16.5
16.5
16.5
 		3
4
5
 		10
10
10
 		56
56
56
 		3 x 6.5
4 x 6.5
5 x 6.5

19.5
19.5
19.5
 		4
5
6
 		10
10
10
 		56
56
63
 		4 x 7.5
5 x 7.5
6 x 7.5

22.5
22.5
22.5
 		5
6
8
 		10
10
10
 		63
63
63
 		5 x 9
6 x 9
8 x 9

25.5
 		6
 		10
 		63
 		6 x 10

28.5
28.5
28.5
 		6
8
10
 		10
10
12
 		63
63
71
 		6 x 11
8 x 11
10 x 11

32.5
32.5
 		8
10
 		10
12
 		63
71
 		8 x 13
10 x 13

45.5
 		10
 		12
 		71
 		10 x 16


B.S.  Cutter  &
Key No.
 		Dia. of Cutter
(Min)
 		Width  of
Cutter
 		Overall Length
 		Dia.  of
Shank

204
304
404
 		0.505
0.505
0.505
 		0.061
0.093
0.124
 		2
2
2
 		1/2
1/2
1/2

305
405
505
 		0.630
0.630
0.630
 		0.093
0.124
0.155
 		2
2
2
 		1/2
1/2
1/2

406
506
606
 		0.755
0.755
0.755
 		0.124
0.155
0.187
 		2-1/4
2-1/4
2-1/4
 		1/2
1/2
1/2

507
607
807
 		0.880
0.880
0.880
 		0.155
0.187
0.249
 		2-1/2
2-1/2
2-1/2
 		1/2
1/2
1/2

608
808
1008
 		1.005
1.005
1.005
 		0.187
0.249
0.311
 		2-3/4
2-3/4
2-3/4
 		1/2
1/2
1/2

609
809
1009
 		1.130
1.130
1.130
 		0.187
0.249
0.311
 		2-3/4
2-3/4
2-3/4
 		1/2
1/2
1/2

810
1010
1210
 		1.255
1.255
1.255
 		0.249
0.311
0.374
 		2-3/4
2-3/4
2-3/4
 		1/2
1/2
1/2

1011
1211
812
 		1.380
1.380
1.380
 		0.311
0.374
0.249
 		3
3
3
 		1/2
1/2
1/2

1012
1212
 		1.505
1.505
 		0.311
0.374
 		3
3
 		1/2
1/2
