Uncoated Carbide Fiberglass Router with End Mill Cut
Zhenjiang Scharp Machinery Tools Co., Ltd.- Coating：Coating
- Tooth Form：Spiral Tooth
- Tooth Space：Sparse Tooth
- Structure：Integral
- Material：Tungsten Steel
- Type：Vertical Milling Cutter
Base Info
- Model NO.：metric and inch
- Size：1.5mm to 25mm
- Standards：DIN, JIS, ANSI,ISO,GOST
- Style：Universal Tool
- Cutting Process：Milling Cutter
- Work Type：Cut off
- Transport Package：Plastic Box, Plastic Tube.
- Specification：1.5mm to 25mm
- Trademark：stc
- Origin：Zhenjiang
- HS Code：82077090
- Production Capacity：10000 PCS,Month
Description
Basic Info.
Model NO. metric and inch Size 1.5mm to 25mm Standards DIN, JIS, ANSI,ISO,GOST Style Universal Tool Cutting Process Milling Cutter Work Type Cut off Transport Package Plastic Box, Plastic Tube. Specification 1.5mm to 25mm Trademark stc Origin Zhenjiang HS Code 82077090 Production Capacity 10000 PCS/MonthProduct Description
| Products Features: | ||||
| 1. Special Cutting Edge: Special cutting edge can increase the cutting ability. The lifetime of tools and machines will be longer | ||||
| 2. Smooth And Wide Flute: wide flute make chips moving faster and easier. | ||||
| 3. High Quality Raw Material: The raw material is used of high toughness, grain-sized carbon tungsten | ||||
| 4. Polished Surface Treatment: With high polished surface treatment, reduce the friction coefficient could be reduced, the lathe efficiency could be improved, more production time could be saved | ||||
| Specifications: | ||||
| Specification | Flute Diameter (mm) | Flute length (mm) | Shank Diameter (mm) | Overall length (mm) |
| D1.0*3*D3.175*38.5 | 1 | 3 | 3.175 | 38.5 |
| D1.5*6*D3.175*38.5 | 1.5 | 6 | 3.175 | 38.5 |
| D1.5*8*D3.175*38.5 | 1.5 | 8 | 3.175 | 38.5 |
| D1.5*12*D3.175*38.5 | 1.5 | 12 | 3.175 | 38.5 |
| D2.0*8*D3.175*38.5 | 2 | 8 | 3.175 | 38.5 |
| D2.0*12*D3.175*38.5 | 2 | 12 | 3.175 | 38.5 |
| D2.0*17*D3.175*38.5 | 2 | 17 | 3.175 | 38.5 |
| D2.5*10*D3.175*38.5 | 2.5 | 10 | 3.175 | 38.5 |
| D2.5*12*D3.175*38.5 | 2.5 | 12 | 3.175 | 38.5 |
| D2.5*17*D3.175*38.5 | 2.5 | 17 | 3.175 | 38.5 |
| D2.5*22*D3.175*45 | 2.5 | 22 | 3.175 | 45 |
| D3.175*12*D3.175*38.5 | 3.175 | 12 | 3.175 | 38.5 |
| D3.175*15*D3.175*38.5 | 3.175 | 15 | 3.175 | 38.5 |
| D3.175*17*D3.175*38.5 | 3.175 | 17 | 3.175 | 38.5 |
| D3.175*22*D3.175*45 | 3.175 | 22 | 3.175 | 38.5 |
| D3.175*25*D3.175*50 | 3.175 | 25 | 3.175 | 38.5 |
| D3.175*28*D3.175*50 | 3.175 | 28 | 3.175 | 38.5 |
| D3.175*32*D3.175*55 | 3.175 | 32 | 3.175 | 38.5 |
| D4*12*D4*45 | 4 | 12 | 4 | 45 |
| D4*15*D4*45 | 4 | 15 | 4 | 45 |
| D4*17*D4*45 | 4 | 17 | 4 | 45 |
| D4*22*D4*45 | 4 | 22 | 4 | 45 |
| D4*25*D4*50 | 4 | 25 | 4 | 45 |
| D4*28*D4*55 | 4 | 28 | 4 | 55 |
| D4*32*D4*60 | 4 | 32 | 4 | 60 |
| D5*17*D5*50 | 5 | 17 | 5 | 50 |
| D5*22*D5*50 | 5 | 22 | 5 | 50 |
| D5*25*D5*50 | 5 | 25 | 5 | 50 |
| D5*32*D5*60 | 5 | 32 | 5 | 60 |
| D5*42*D5*70 | 5 | 42 | 5 | 70 |
| D6*17*D6*50 | 6 | 17 | 6 | 50 |
| D6*22*D6*50 | 6 | 22 | 6 | 50 |
| D6*25*D6*50 | 6 | 25 | 6 | 50 |
| D6*28*D6*55 | 6 | 28 | 6 | 55 |
| D6*32*D6*55 | 6 | 32 | 6 | 55 |
| D6*35*D6*60 | 6 | 35 | 6 | 60 |
| D6*42*D6*75 | 6 | 42 | 6 | 75 |
| D6*52*D6*75 | 6 | 52 | 6 | 75 |
| D6*62*D6*100 | 6 | 62 | 6 | 100 |
| D8*17*D8*60 | 8 | 17 | 8 | 60 |
| D8*22*D8*60 | 8 | 22 | 8 | 60 |
| D8*25*D8*60 | 8 | 25 | 8 | 60 |
| D8*32*D8*60 | 8 | 32 | 8 | 60 |
| D8*42*D8*75 | 8 | 42 | 8 | 75 |
| D8*52*D8*100 | 8 | 52 | 8 | 100 |
| D10*22*D10*75 | 10 | 22 | 10 | 75 |
| D10*32*D10*75 | 10 | 32 | 10 | 75 |
| D10*42*D10*75 | 10 | 42 | 10 | 75 |
| D10*52*D10*100 | 10 | 52 | 10 | 100 |
| D12*22*D12*75 | 12 | 22 | 12 | 75 |
| D12*32*D12*75 | 12 | 32 | 12 | 75 |
| D12*42*D12*75 | 12 | 42 | 12 | 75 |
| D12*52*D12*100 | 12 | 52 | 12 | 100 |
