High Speed Steel T-Slot Cutter

Zhenjiang Scharp Machinery Tools Co., Ltd.
  • Coating：Uncoated
  • Tooth Form：Straight Tooth
  • Tooth Space：Sparse Tooth
  • Structure：Integral
  • Material：High Speed Steel
  • Type：Vertical Milling Cutter

Base Info

  • Model NO.：standard
  • Size：12mm to 40mm
  • Work Type：Cut off
  • Transport Package：Plastic Box
  • Specification：DIN 851, ANSI
  • Trademark：stc
  • Origin：Jiangsu
  • HS Code：82077090
  • Production Capacity：1000pcs,size

Description

Basic Info.

Model NO. standard Size 12mm to 40mm Work Type Cut off Transport Package Plastic Box Specification DIN 851, ANSI Trademark stc Origin Jiangsu HS Code 82077090 Production Capacity 1000pcs/size

Product Description

High Speed Steel T-Slot CutterHigh Speed Steel T-Slot CutterHigh Speed Steel T-Slot CutterHigh Speed Steel T-Slot CutterDIN851 ANSI B94.19 T slot cutters

T slot cutters are used primarily for milling T-slots in machine tables.
T slot cutters have straight shank right hand cut made from high speed steel.
A vertical slot must be cut first, so shank and neck of cutter can enter the slot.

High Speed Steel T-Slot Cutter
BOLT SIZE
 		d
 		W
 		d 2
 		I 1
 		d 1
 		NO. OF
TEETH

6
8
10
12
14
16*
18
20*
22
 		12.5
16
18
21
25
28
32
36
 		6
8
8
9
11
12
14
16
18
 		5
7
8
10
12
13
15
17
19
 		55
60
62
68
70
75
90
95
100
 		10
10
12
12
16
16
25
25
25
 		6
6
6
6
8
8
8
10
10


BOLT SIZE
 		d
 		W
 		d 2
 		I 1
 		d 1
 		NO. OF
TEETH

1/4
5/16
3/8
7/16
1/2
5/8
3/4
7/8
1"
 		37/64
45/64
53/64
61/64
1.5/64
1.21/64
1.33/64
1.45/64
1.61/64
 		1/4
5/16
23/64
27/64
15/32
37/64
11/16
51/64
29/32
 		7/32
9/32
11/32
13/32
15/32
9/16
11/16
13/16
15/16
 		2.3/8
2.9/16
2.11/16
2.7/8
3.1/8
3.13/16
4.1/8
4.7/16
4.15/16
 		1/2
1/2
1/2
1/2
1/2
1"
1"
1"
1"
 		6
6
6
8
8
8
10
10
10
