Table 400X400mm X 2, Two-Table Pallet Changer Rotary

Songen Machinery Co., Ltd.
  • Certification：CE, ISO 9001:2008, GS
  • Material：Metal
  • Type：Pallet Exchanging
  • Pallet Table：400X400mm
  • Table Rotation Diameter：500mm
  • Pallet Rotary Diameter：1260mm

Base Info

  • Model NO.：NCRT400X400X2
  • Worm Gear Ratio：1:150
  • Total Ratio：1:180
  • Weight Loading Capacity：400kg
  • Logo Printing：with Logo Printing
  • Size：Middle
  • Customized：Customized
  • Transport Package：Plywood Case
  • Specification：400x400x2
  • Trademark：Songen
  • Origin：China
  • HS Code：84663000
  • Production Capacity：1000 Sets,Year

Description

ParameterNCRT400X400X21Dimension of pallet (length X width), mm400X4002Table rotation diameter, mm5003Pallet rotary diameter, mm12604Worm gear ratio1:1505Total ratio1:1806Max. load capacity, Kgf4007Servo motor (optional)FANUC α12i or α8i8Max. clamping torque, Kgf.m2009Min. indexing increment, Deg0.00110Dividing and repeatability accuracy, Sec15±2.511Repeatability accuracy of pallet, mm0.0112Max. working pressure, MpaOil3.5Air0.613Clamping force of pallet, Kgf350014Diameter of pallet center hole, mm50H715Total thickness, mm37216Time of changing pallet, Sec1517Up-down distance of changing pallet, mm45
