Solid Carbide Taper Pin Ball Nose End Mills
Zhenjiang Scharp Machinery Tools Co., Ltd.- Coating：Coating
- Tooth Form：Spiral Tooth
- Tooth Space：Sparse Tooth
- Structure：Integral
- Material：Cemented Carbide
- Type：Vertical Milling Cutter
Base Info
- Model NO.：metric and inch
- Transport Package：Plastic Box
- Specification：3mm to 20mm
- Trademark：stc
- Origin：Jiangsu
- HS Code：8207409000
- Production Capacity：10000 PCS Per Month
Description
Basic Info.
Model NO. metric and inch Transport Package Plastic Box Specification 3mm to 20mm Trademark stc Origin Jiangsu HS Code 8207409000 Production Capacity 10000 PCS Per MonthProduct Description
| Flute Dia.(mm) | Flute Length(mm) | Shank Dia.(mm) | Overall Length(mm) |
| R0.25 | 15 | Φ4 | 50 |
| R0.5 | 15 | Φ4 | 50 |
| R0.75 | 15 | Φ4 | 50 |
| R1 | 15 | Φ4 | 50 |
| R0.25 | 20.5 | Φ4 | 50 |
| R0.5 | 20.5 | Φ4 | 50 |
| R0.75 | 20.5 | Φ4 | 50 |
| R1 | 20.5 | Φ4 | 50 |
| R0.25 | 20.5 | Φ4 | 75 |
| R0.5 | 20.5 | Φ4 | 75 |
| R0.75 | 20.5 | Φ4 | 75 |
| R1 | 20.5 | Φ4 | 75 |
| R0.25 | 20 | Φ6 | 50 |
| R0.5 | 20 | Φ6 | 50 |
| R0.75 | 20 | Φ6 | 50 |
| R1 | 20 | Φ6 | 50 |
| R0.25 | 30.5 | Φ6 | 75 |
| R0.5 | 30.5 | Φ6 | 75 |
| R0.75 | 30.5 | Φ6 | 75 |
| R1 | 30.5 | Φ6 | 75 |
| R1.5 | 30.5 | Φ6 | 75 |
| R2 | 30.5 | Φ6 | 75 |
| R0.25 | 47 | Φ8 | 85 |
| R0.5 | 47 | Φ8 | 85 |
| R0.75 | 47 | Φ8 | 85 |
| R1 | 47 | Φ8 | 85 |
| R1.5 | 47 | Φ8 | 85 |
| R2 | 47 | Φ8 | 85 |
| R0.25 | 60 | Φ8 | 100 |
| R0.5 | 60 | Φ8 | 100 |
| R0.75 | 60 | Φ8 | 100 |
| R1 | 60 | Φ8 | 100 |
| R1.5 | 60 | Φ8 | 100 |
| R2 | 60 | Φ8 | 100 |
