Hssal Single Flute End Mills for Fiberglass
Zhenjiang Scharp Machinery Tools Co., Ltd.- Coating：Coating
- Tooth Form：Spiral Tooth
- Tooth Space：Sparse Tooth
- Structure：Integral
- Material：High Speed Steel
- Type：Vertical Milling Cutter
Base Info
- Model NO.：metric
- Size：3mm to 10mm
- Standards：64HRC
- Style：Universal Tool
- Cutting Process：Milling Cutter
- Work Type：Miling
- Transport Package：Plastic Box
- Specification：3mm to 10mm
- Trademark：stc
- Origin：Zhenjiang
- HS Code：82077090
- Production Capacity：10000PCS Per Month
Description
Basic Info.
Model NO. metric Size 3mm to 10mm Standards 64HRC Style Universal Tool Cutting Process Milling Cutter Work Type Miling Transport Package Plastic Box Specification 3mm to 10mm Trademark stc Origin Zhenjiang HS Code 82077090 Production Capacity 10000PCS Per MonthProduct Description
One-flute end mills designed for cutting soft materials such as PTFE and flexible laminates.
It is made from high speed steel M2 or cobalt high speed steel M35.
regular length and long length available on request.
special design available on request.
Tin or TIALN coating available on request.
| flute no | diameter | shank | flute length | total length |
| 1 | 3 | 8 | 12 | 60 |
| 1 | 4 | 8 | 12 | 60 |
| 1 | 5 | 8 | 14 | 60 |
| 1 | 6 | 8 | 14 | 60 |
| 1 | 7 | 8 | 14 | 60 |
| 1 | 8 | 8 | 14 | 80 |
| 1 | 9 | 8 | 14 | 80 |
| 1 | 10 | 8 | 14 | 80 |
