Nc Horizontal and Vertical Dividing Heads
Songen Machinery Co., Ltd.- Certification：ISO9001:2008, CE, ISO 9001:2008, GS
- Application：Boring Machine
- Function：Universal
- Structure：Vertical And Horizontal
- Dividing Type：Worm Type
- Material：Carbon Steel
Base Info
- Model NO.：NCDH140E, NCDH175E, NCDH220E
- Type：CNC Controlled
- Center Height：140, 175, 220mm
- Dividing Accuracy：10"
- Repeatability Accuracy：3"
- Logo Printing：with Logo Printing
- Size：Middle
- Customized：Customized
- Transport Package：Plywood Case
- Specification：Center Heights 140, 175, 220mm, Nc Control, 5-Deg
- Trademark：Songen
- Origin：China
- HS Code：84663000
- Production Capacity：1000 Sets,Year
Description
SpecificationsNCDH140E NCDH175E NCDH220E Center height, mm 140 175 220 Diameter of table, mm 160 200 315 T-slot size, mm 10H10 10H10 14H10 Angle of T-slot, Deg 90 90 60 Diameter of centering bushing, mm 20H7 25H7 30H7 Diameter of indexer tram bushing, mm 10H7 10H7 15H7 Width of indexer positioning key, mm 18 Number of teeth on face gear coupling 72 Angles of equal dividing, Deg Integer times of 5 Air/oil pressure for spindle clamping & loosing, MPa Air: 0.5~0.7MPa Oil: 0.5~2MPa Servo motor power, KW 0.3 Servo motor torque, N.m ≥2 ≥3 ≥5 Dividing accuracy, Sec 10 Repeatability accuracy, Sec 3 Max. load capacity, Kgf Spindle horizontally mounted 50 75 150 Spindle vertically mounted 100 250 350
