• Model NO.：Customized
• Function：Cutting
• Shape：Band Saw Blade
• Coating：Uncoated
• Type：Carbide Saw Blade
• Size：Customized
• Material：Tungsten Carbide
• Standards：Hra
• Style：Universal Tool
• Structure：Special Type
• Cutting Process：Turning Tools
• Work Type：Cut Off
• Transport Package：Carton Box
• Specification：ISO
• Trademark：Excelledge
• Origin：Chengdu, China
• HS Code：82090000
• Production Capacity：20, 000 PCS,Month
• Package size per unit product：16.00cm * 1.50cm * 0.60cm
• Gross weight per unit product：0.250kg

Basic Info.

Model NO. Customized Function Cutting Shape Band Saw Blade Coating Uncoated Type Carbide Saw Blade Size Customized Material Tungsten Carbide Standards Hra Style Universal Tool Structure Special Type Cutting Process Turning Tools Work Type Cut Off Transport Package Carton Box Specification ISO Trademark Excelledge Origin Chengdu, China HS Code 82090000 Production Capacity 20, 000 PCS/Month

Packaging & Delivery

Package size per unit product 16.00cm * 1.50cm * 0.60cm Gross weight per unit product 0.250kg

Product Description

We are a professional manufacturer of Cemented Carbide Tools, and can supply you with kinds of standard and special standard Cutting Tools.

The Cemented Carbide Tools is good at hardness and wear resistance, the tool life always is 3~10 times of the one made by tool steel. The cost-effective is obviously due to the long tool life.

The Cuttig Tools made by Cemented Carbide can be finishing proceed by CNC machines and EDM, so the cutting tools could be designed to different sizes and tolerances.

The Cemented Carbide Cutting Tools also can be made according to your own specification.

Grades of Tungsten Carbide Tools are as follows:


Grade	Density	Hardness (HRA)	Bending Strength (/Mpa)	Performance and Application	Equivalent ISO Grade
YG3X	15.0~15.3	92	1320	Fine Grain Size, outstanding in hardness, which is used to high speed finishing of cast iron, non-ferrous alloy, and  alloy hardened steel, and alloy steel.	K01
YG3	15.0~15.3	91	1200	Excellent in hardness, and suitable for finishing of cast iron, non-ferrous alloy, and plastic, rubber, etc.	K01
YG6X	14.6~15.0	91	1400	Fine grain size. Excellent in wear resistance.Be used to process ferrous steel (HB<200), glass, hard rubber, cardboard, marble, ceramic copper alloy etc.	K10
YG6	14.6~15.0	89.5	1450	Be used to process ferrous steel(HB<200),non-ferrous metal, wood, plastic, etc.	K20
YG8	14.5~14.9	89	1500	Rough and semi-finishing of cast iron, nonferrous metal, wood, plastic, etc.	K30
YG11C	14.0~14.4	86.5	2100	Grade for manufacturing nozzle, wear resistance parts, die insert, mining tool, measuring tool like gauge, micrometer etc	K40
YG15	13.9~14.2	87	2100	Grade for manufacturing nozzle, wear resistance parts, die insert, mining tool, measuring tool like gauge, micrometer etc	K40
YG20	13.4~13.7	85.5	2600	Excellent in toughness and suitable for punching mold.	K40
YG20C	13.4~13.7	85	2650	Excellent in toughness and suitable for cold heading, cold punching, cold pressing mold, and punching mold.	K40
YG25	12.9~13.2	84.5	2700	Excellent in toughness and suitable for cold heading, cold punching, cold pressing mold, and punching mold.	K40
YT5	12.5~13.2	89.5	1400	Roughing of carbon steel and alloy steel.	P30
YT14	11.2~13.2	90.5	1200	Semi-finishing and finishing of carbon steel, alloy steel.	P20
YT15	11.0~12.7	91	1150	Semi-finishing and finishing of carbon steel, alloy steel.	P10
YW1	12.6~13.5	91.5	1200	Be used to processi refractory steel,stainless steel, high manganese steel, cast iron.	M10
YW2	12.4~13.5	90.5	1350	Be used to process refractory steel,stainless steel,high manganese steel,cast iron.	M20
YW3	12.7~13.3	92	1400	Excellent in resistance for wear and high temperature shock, which is used for finishing and semi-finishing of heat resisting alloy steel, high strength steel,  extra-high strength steel, low alloy steel.	M30
YW4	12.1~12.5	92	1300	Outstanding resistance for high temperature and anti-plastering, general purpose grade. It is suitable for carbon steel, mostly alloy steel beside Ni-based steel, and designed for finishing of heat resistance stainless steel.	M40
