• Model NO.：CH-112
• Type：Cutter
• Saw Type：Circular Saw
• Teeth Shape：Tb,Tcg,FT,Conical
• Finishing：White
• OEM：Accepted
• Size：205mm-400mm
• Work Type：Cut off
• Material：65mn or 75cr1
• Transport Package：Color Boxes
• Specification：TUV
• Trademark：CH
• Origin：Zhejiang , China
• HS Code：8202
• Production Capacity：350000PCS Per Month

Basic Info.

Model NO. CH-112 Type Cutter Saw Type Circular Saw Teeth Shape Tb/Tcg/FT/Conical Finishing White OEM Accepted Size 205mm-400mm Work Type Cut off Material 65mn or 75cr1 Transport Package Color Boxes Specification TUV Trademark CH Origin Zhejiang / China HS Code 8202 Production Capacity 350000PCS Per Month

Product Description

Premium Quality Saw Blade for Aluminum
1. Body: 65Mn or 75Cr1 as steel body.
2. CNC machining with good finish edge.
3. Carbide tip: CERATIZIT from Luxemburg.
4. Sandwiche Soldering Flake.
5. Long working time.
6. Different quality grade choose.
7. Artwork design service.

Aluminum cutting saw blades

Materials:
1. Tungsten Carbide tip from Ceratizit, Luxemburg, KCR05/06
2. Saw body: 75Cr1 from Grasche Group, Germany.
3. Technology conducted by German expert, quality up to the standard of German DIN54, DIN8033.
4. Saw body: High quality steel plate.
Application:
1. For cutting aluminum alloy, non-ferrous metal.
2. Used on table saw, Precision panel saw.
Advantages:
1. High bending resistance makes carbide tip difficult to be broken.
2. Over ten years experience, free consult service.
3. Best material with advanced machines.
4. Deformation will not happen after long time using.
5.15 years experience, free consult service

Out diameter(ΦD)	Tooth width(B)mm	Tooth thickness(Φb)mm	Inner diameter(d)mm	Number of Teeth(Z)
205	2.0	1.4	25.4	80
205	2.8	2.2	25.4	80
205	2.0	1.4	25.4	100
205	2.8	2.2	25.4	100
250	3.0	2.4	25.4	80
250	2.6	2.0	25.4	100
250	3.0	2.4	25.4	100
250	2.6	2.0	25.4	120
250	3.0	2.4	25.4	120
300	2.6	2.0	25.4	100
300	3.0	2.4	25.4	100
350	3.0	2.4	25.4	100
350	3.6	3.0	25.4	100
400	3.0	2.4	25.4	100
400	3.6	3.0	25.4	100
400	3.0	2.4	25.4	120
