• Model NO.：metric
• Size：1,16 to 1,4 Inch
• Standards：K-N
• Style：Universal Tool
• Cutting Process：Milling Cutter
• Work Type：Cut off
• Transport Package：Plastic Box
• Specification：1,16 to 1,2
• Trademark：stc
• Origin：Jiangsu
• HS Code：82077090
• Production Capacity：10000 PCS Per Month

Basic Info.

Model NO. metric Size 1/16 to 1/4 Inch Standards K-N Style Universal Tool Cutting Process Milling Cutter Work Type Cut off Transport Package Plastic Box Specification 1/16 to 1/2 Trademark stc Origin Jiangsu HS Code 82077090 Production Capacity 10000 PCS Per Month

Product Description







The double end mills are made from high quality of high speed steel M2. its chemical composition is W6Mo5Cr4V2. hardness 64hrc.



Our double ended end mills are made from super quality high speed steel M2.

Its hardness is 62 to 64 HRC.

Tialn and Tin coating available on request.

Center cutting.

4 flute and 2 flute available.

Laser marking.

Stub length and long length available.

Plastic box industrial packing.

NC fully ground.

Size	Shank Diameter	Length of Cut	Overall Length	Flutes
1/16	1/8	1/8	1-1/2	4
3/32	1/8	3/16	1-1/2	4
1/8	1/8	1/4	1-1/2	4
5/32	3/16	5/16	2	4
3/16	3/16	3/8	2	4
7/32	1/4	1/2	2-1/2	4
1/4	1/4	1/2	2-1/2	4
5/16	5/16	1/2	2-1/2	4
3/8	3/8	9/16	2-1/2	4
7/16	7/16	9/16	2-3/4	4
1/2	1/2	5/8	3	4
